ChargePapa Power-Bridge | GB/T to Type 1 Adapter (32A / AC 110-250V)

On sale Save $29.00 USD (20% off)
$114.55 USD
$143.55 USD $114.55 USD
Sale Sold out
Shipping calculated at checkout.
🛡️ Quality Assurance: Every unit undergoes a rigorous 72-hour high-voltage stress test and thermal calibration before dispatch from our global hub. Safety is our priority; quality is non-negotiable.
✅ CE/TUV Safety Certified
🛡️ 2-Year Replacement Warranty
📦 Free Global Shipping

Power-Bridge | GB/T (GB/T 20234.2) → Type 1 (SAE J1772) Adapter


The ChargePapa Power-Bridge CP-KL-ADP-028 enables GB/T 20234.2 electric vehicles to charge at SAE J1772 Type 1 AC stations — the standard charging infrastructure across North America and Japan. With wide-voltage support from AC 110V to 250V and a 32A maximum current rating, this adapter gives Chinese-standard EV owners seamless access to J1772 charging infrastructure when travelling or relocating to North America or Japan. Built with silver-plated copper alloy conductors and a rugged PC+PA66 housing, it is rated for over 10,000 charge cycles in all weather conditions.

GB/T to Type 1 Adapter (32A / AC 110-250V)

GB/T → Type 1 Product Line
Model Current Max Power Best For
Power-Bridge (This) 32A MAX ~7.4 kW Standard AC Level 2 charging
Omni-Link Pro 50A MAX ~11.5 kW Higher capacity onboard chargers
Engineering Data Sheet
SKU CP-KL-ADP-028
Input Connector SAE J1772 Type 1 (Female) — Station Side
Output Connector GB/T 20234.2 (Male) — Vehicle Side
Working Voltage AC 110V ~ 250V (Wide Voltage)
Rated Current 32A MAX
Max Power Output ~7.4 kW @ 230V · ~3.5 kW @ 110V (Single-phase)
Phase Type Single-phase
Terminal Temp Rise <50K
Case Material PC + PA66
Conductor Material Copper alloy with silver plating
Insertion Force 45N < F < 100N
Plug/Unplug Life >10,000 cycles
Product Dimensions 166.7 × 70.0 × 69.9 mm
Working Temperature -30°C to +50°C (-22°F to +122°F)
Working Humidity 5% ~ 95% RH
Working Altitude ≤2000m
Compatibility
Station Side (Input) Vehicle Side (Output) Charging Type
SAE J1772 Type 1 AC Station GB/T 20234.2 EV Port AC Level 2 Only
Compatible with GB/T 20234.2 standard EVs including BYD, NIO, XPENG, Li Auto, Geely, and other Chinese-market electric vehicles. Allows these vehicles to charge at SAE J1772 Type 1 AC stations across North America and Japan.
✅ Standards & Certifications

CE — Conformité Européenne: Meets EU safety, health, and environmental protection requirements.

FCC — Federal Communications Commission: Compliant with electromagnetic interference standards for use in North America.

Frequently Asked Questions

Q: Which vehicles are compatible with the CP-KL-ADP-028?

A: Compatible with all GB/T 20234.2 standard EVs including BYD, NIO, XPENG, Li Auto, Geely, and other Chinese-market electric vehicles. Allows these vehicles to charge at SAE J1772 Type 1 AC stations in North America and Japan.

Q: What is the maximum charging speed?

A: Up to 32A MAX. At AC 230V approximately 7.4 kW; at AC 110V approximately 3.5 kW. Actual speed depends on your vehicle’s onboard charger and the station’s output rating.

Q: How does this compare to the Omni-Link GB/T to Type 1 Pro?

A: The Power-Bridge CP-KL-ADP-028 is rated at 32A MAX (standard grade), while the Omni-Link Pro supports up to 50A MAX. Choose based on your vehicle’s onboard charger rating and the station’s capacity.

Q: Does this adapter support DC fast charging?

A: No. The CP-KL-ADP-028 supports AC Level 2 single-phase charging only. For DC fast charging solutions, please refer to ChargePapa’s DC-Link adapter series.

⚠️ Critical Usage Note

This adapter is designed for AC Level 2 single-phase charging only. Do not use with DC fast chargers.

Always verify that your charging station output does not exceed 32A / 250V before use.
